Piston kit Wossner Honda XR 600 + 1.00 mm bore size 98 mm

Honda XR600R, for years 1985-2001 , Wossner piston kit for bore size 98 mm, Wossner piston size 97,94 mm,  High performance piston from Germany.

• Oversize +1.00 mm = Wossner piston size 97,94 mm
• Honda XR600R years 1985 – 2001
• • Bore Size: 98.00mm (Actual Size: 97.94mm)
  • Wössner Part Number: 8574D100
  • Lock Part Number: CW23
  • Pin Part Number: WP057
  • Ring Set Part Number: 980XSY
  • Rod Part Number: P4028
  • Displacement: 654 cm³
  • Stroke: 80.00mm
  • Clearance: 0.06mm
  • Compression Ratio: 9.30:1
  • OEM Compression Ratio: 9.00:1
  • Dome Volume: -4.80 cm³
  • Compression Height: 29.70mm
  • Theoretical Weight: 348.00g
• In-house designed and manufactured; all forgings are produced in Wössner’s company-owned forging operation
• 4-stroke pistons are made using a double-bridged forging design
• Lightweight pistons with the tightest piston-wall clearances in the industry give you a quieter running engine
• Standard and oversize pistons for most models, with high compression ratios available for 4-stroke applications
• All piston skirts are supplied with a Moly coating to reduce friction and assist in break in
• All piston kits include piston, ring, wrist pin and pin locks
• Wössner piston kits are used by leading Supercross, Arenacross and MX GP teams
